150 S450 Operation & Maintenance Manual
REAR GRILLE
Removing
Stop the engine and open the rear door.
Figure 194
Lift and pull the rear grille backward to remove from the
loader [Figure 194].
Installing
Figure 195
The front edge of the rear grille has two tabs that fit into
slots in the loader frame (Item 1) [Figure 195]. Insert the
tabs into the slots and lower the rear grille.
Close the rear door.
