162 S450 Operation & Maintenance Manual
ENGINE LUBRICATION SYSTEM (CONT’D)
Removing And Replacing Oil And Filter
See the SERVICE SCHEDULE for the correct service
interval. (See SERVICE SCHEDULE on Page 134.)
Operate the engine until coolant reaches normal
operating temperature. Stop the engine.
Figure 218
The oil drain hose is located behind a cover (Item 1)
under the rear of the loader (Inset) [Figure 218].
Loosen one cover mounting bolt and remove the other
bolt (Item 2) [Figure 218] to allow the cover to swing
open.
Open the rear door.
Figure 219
The oil drain hose (Item 1) [Figure 219] storage location
is near the fuel tank fill. Route the oil drain hose through
the opening.
Figure 220
Remove the oil drain cap (Item 1) [Figure 220] from the
oil drain hose and drain the oil into a container. Recycle
or dispose of used oil in an environmentally safe manner.
Install and tighten the oil drain cap [Figure 220].
Return the oil drain hose to the storage location
[Figure 219].
Close the cover and install the cover mounting bolt
[Figure 218]. Tighten both bolts.
