AVOID INJURY OR DEATH
Batteries contain acid which burns eyes and skin on
contact. Wear goggles, protective clothing and
rubber gloves to keep acid off body.
In case of acid contact, wash immediately with water.
In case of eye contact get prompt medical attention
and wash eye with clean, cool water for at least 15
minutes.
If electrolyte is taken internally drink large quantities
of water or milk! DO NOT induce vomiting. Get
prompt medical attention.
W-2065-0807
Figure 241
Always clean the battery terminals and cable ends when
installing a new or used battery [Figure 241].
Install the battery wrap onto the battery.
When installing the battery into the loader, do not touch
any metal parts with the battery terminals.
Install the battery into the loader.
Slightly raise the battery wrap to allow the battery to lock
into the battery clamps.
Figure 242
Install the battery clamp (item 2) and the nut (Item 1)
[Figure 242].
Lower the battery wrap over the battery clamps.
Figure 243
Connect and tighten the positive (+) cable (Item 2).
Connect and tighten the negative (-) cable (Item 1)
[Figure 243] last to prevent sparks.
Put Bobcat Battery Saver or grease on the battery
terminals and cable ends to prevent corrosion.
Close and securely fasten the top flap of the battery wrap
[Figure 238].
Close the rear door.
