47 S450 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION (CONT’D)
Left Panel (Cont’d)
* This manual contains a table with Service Code descriptions. (See DIAGNOSTIC SERVICE CODES on Page 201.)
ITEM DESCRIPTION FUNCTION / OPERATION
12 RIGHT TURN SIGNAL (Option) Indicates right turn signals are ON.
13
DIESEL PARTICULATE FILTER
(DPF) / DIESEL EXHAUST FLUID
(DEF)
Not used.
14 SHOULDER BELT (Option)
Instructs operator to fasten shoulder belt when operating in high range.
Remains lit while in high range.
15
HYDRAULIC SYSTEM
MALFUNCTION
Hydraulic system malfunction or failure. (See Service Codes*)
16 FUEL Fuel level low or sensor error.
17 FUEL GAUGE Shows the amount of fuel in the tank.
18
LIGHTS without road option
Press once for REAR taillights. (Right green LED will light.) Press a
second time to turn FRONT and REAR work lights ON. REAR taillights
will turn OFF. (Left green LED will light.) Press a third time to turn all
lights off. (Left and right green LEDs will be off.)
LIGHTS with road option
Press once for FRONT boom light, license plate light and REAR
taillights. (Right green LED will light.) Press a second time to turn
FRONT and REAR work lights ON. FRONT boom light, license plate
light and REAR taillights will turn OFF. (Left green LED will light.) Press
a third time to turn all lights off. (Left and right green LEDs will be off.)
Press and hold 5 seconds to display software version in display screen.
19
AUTO IDLE Not used.
Move cursor to the left inside the DISPLAY SCREEN when using
certain INFORMATION button menus.
20
AUXILIARY HYDRAULICS
Press once to activate the auxiliary hydraulic system. (Left green LED
lights.) Press a second time to deactivate the system.
Move cursor to the right inside the DISPLAY SCREEN when using
certain INFORMATION button menus.
21 INFORMATION
Cycles through (after each button press):
• Hourmeter (On startup)
•Engine rpm
• Battery voltage
• Drive response menu
• Steering drift compensation menu
• Maintenance clock
• Service codes*
22 TRACTION LOCK OVERRIDE
Functions only when the seat bar is raised and the engine is running.
Press once to unlock the brakes. Allows you to use the steering levers
or joystick(s) to move the loader forward or backward when using the
backhoe attachment. (See TRACTION LOCK OVERRIDE in this
manual.) Press a second time to lock the brakes.
23 PRESS TO OPERATE LOADER
Press to activate the BICS™ when the seat bar is down and operator is
seated in operating position. Button will light.
24
PARKING BRAKE (Standard on all
loaders)
Press the top to engage the Parking Brake. Press the bottom to
disengage. (See PARKING BRAKE in this manual.)
