49 S450 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION (CONT’D)
Right Panel (Standard Key Panel)
Figure 14
This machine may be equipped with a Standard Key
Panel [Figure 14].
The Standard Key Panel has a key switch (Item 1)
[Figure 14] used to turn the loaders electrical system on
and off, and to start and stop the engine.
The switch location (Item 2) [Figure 14] can have
different functions depending on machine configuration.
See the following table for more information.
P-85285
1
2
ITEM DESCRIPTION
FUNCTION /
OPERATION
ADVANCED
CONTROL SYSTEM
(ACS) (Option)
Press the top to
select Hand
Controls; bottom to
select Foot Controls.
SELECTABLE
JOYSTICK
CONTROLS (SJC)
(Option)
Press the top to
select ‘ISO’ Control
Pattern; bottom to
select ‘H’ Control
Pattern.
FOUR-WAY
FLASHER LIGHTS
(Option)
Press the top to turn
lights ON; bottom to
turn OFF.
ROTATING BEACON
(Option)
OR
STROBE LIGHT
(Option)
Press the top to turn
light ON; bottom to
turn OFF.
