50 S450 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION (CONT’D)
Right Panel (Keyless Start Panel)
Figure 15
This machine may be equipped with a Keyless Start
Panel [Figure 15].
1. Keypad (keys 1 through 0): Used to enter a number
code (password) to allow starting the engine. An
asterisk will show in the left panel display screen for
each key press.
2. LOCK Key: Used to lock keypad. The lock key will
display a red light to indicate a password is required
to start the loader. (See Password Lockout Feature
on Page 211.)
3. UNLOCK Key: Used to unlock keypad. The unlock
key will display a green light to indicate the loader can
be started without a password. (See Password
Lockout Feature on Page 211.)
4. Key Switch: Used to turn the loaders electrical
system on and off, and to start and stop the engine.
The switch location (Item 5) [Figure 15] can have
different functions depending on machine configuration.
See the following table for more information.
