97 S450 Operation & Maintenance Manual
PRE-STARTING PROCEDURE (CONT’D)
Seat Bar
Figure 101
Lower the seat bar and engage the parking brake
[Figure 101].
Put the foot pedals or hand controls in neutral position.
NOTE: Keep your hands on the steering levers and
your feet on the foot pedals (or footrests)
while operating the loader.
AVOID INJURY OR DEATH
When operating the machine:
• Keep the seat belt fastened snugly.
• The seat bar must be lowered.
• Keep your feet on the pedal controls or footrests
and hands on the controls.
W-2261-0909
Joystick Position Adjustment
Joystick Position Adjustment is available on SJC
equipped machines.
Figure 102
Pull the joystick adjustment lever (Item 1) [Figure 102]
up to slide the loader joystick forward or backward to
adjust for comfortable operation. (Right side shown.)
