AVOID SERIOUS INJURY OR DEATH
• Engines can have hot parts and hot exhaust gas.
Keep flammable material away.
• Do not use machines in atmosphere containing
explosive dust or gases.
W-2051-0212
Perform the PRE-STARTING PROCEDURE. (See PRE-
STARTING PROCEDURE on Page 94.)
Figure 103
Set the engine speed control to the low idle position
[Figure 103].
Figure 104
Turn the key switch to RUN (Item 1) [Figure 104]. The
indicator lights on the left instrument panel will come ON
briefly and the instrument panel / monitoring system will
perform a self test.
Figure 105
The machine will cycle the glow plugs automatically
based on temperature. The engine preheat icon (Item 1)
and the cycle time remaining (Item 2) [Figure 105] are
displayed in the data display.
When the engine preheat icon goes OFF, turn the key
switch to START (Item 2). Release the switch when the
engine starts and allow the switch to return to the RUN
position (Item 1) [Figure 104].
To Next Page
