99 S450 Operation & Maintenance Manual
STARTING THE ENGINE (CONT’D)
Standard Key Panel (Cont’d)
NOTE: Make sure both hand controls (ACS) or
joysticks (SJC) are in the neutral position
before starting the engine. Do not move the
levers or joysticks from the neutral position
when turning the key switch to RUN or START
with the BICS™ activated.
AVOID INJURY OR DEATH
• Fasten seat belt, start and operate only from the
operator’s seat.
• Never wear loose clothing when working near
machine.
W-2135-1108
Figure 106
(ACS) Select hand control or foot pedal operation (Item
1) [Figure 106] if equipped with ACS.
OR
(SJC) Select ‘ISO’ or ‘H’ Control Pattern (Item 2)
[Figure 106] if equipped with SJC.
Figure 107
Press the PRESS TO OPERATE LOADER button (Item
1) [Figure 107] to activate the BICS™ and to perform
hydraulic and loader functions.
(SJC) The current drive response setting is displayed
briefly in the data display (Item 2) each time the PRESS
TO OPERATE LOADER button (Item 1) [Figure 107] is
pressed.
NOTE: (SJC) The light of the current switch position
(ISO or H) will flash, which indicates PRESS
TO OPERATE LOADER is required. The light
will flash when the key switch is in the RUN
position and continue to flash until the PRESS
TO OPERATE LOADER button is pressed,
then the light will become solid. If the mode
(ISO / H) is changed while driving, the active
mode light will remain solid and the pending
mode light will flash. When operation of the
machine is returned to neutral, the active
mode light will turn off and the pending mode
light will continue to flash until the PRESS TO
OPERATE LOADER button is pressed.
AVOID INJURY OR DEATH
When an engine is running in an enclosed area, fresh
air must be added to avoid concentration of exhaust
fumes. If the engine is stationary, vent the exhaust
outside. Exhaust fumes contain odorless, invisible
gases which can kill without warning.
W-2050-0807
