201 S650 Operation & Maintenance Manual
(S650) LOADER SPECIFICATIONS
Machine Dimensions
• Dimensions are given for loader equipped with standard tyres and 74 in. Construction & Industrial bucket and may
vary with other bucket types. All dimensions are shown in millimeters. Respective imperial dimensions are given in
inches enclosed by parentheses.
• Where applicable, specifications conform to SAE or ISO standards and are subject to change without notice.
Changes of structure or weight distribution of the loader can cause changes in control and steering response and
can cause failure of the loader parts.
NA1660
1832 mm
(72.1 in)
1507 mm
(59.3 in)
2106 mm
(82.9 in)
1880 mm
(74 in)
3149 mm
(124 in)
2447 mm
(96.3 in)
800 mm
(31.5 in)
42°
97°
31.1°
25.2°
4026 mm
(158.5 in)
2065 mm
(81.3 in)
207 mm
(8.1 in)
1150 mm
(45.3 in)
2753 mm
(108.4 in)
3474 mm
(136.8 in)
