53 S650 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION (CONT’D)
Radio (Cont’d)
REF.
NO.
DESCRIPTION FUNCTION / OPERATION
1 POWER Press to turn ON; press again to turn OFF.
2 MUTE Press to mute audio output; MUTE will appear in display screen; press again to turn OFF.
3 DISPLAY Press to toggle between function mode (showing tuner frequency, auxiliary input, weather
band information or timer) and clock mode.
Press and hold to enter clock setting mode; use FREQUENCY DOWN button to adjust
hours and FREQUENCY UP button to adjust minutes; normal operation will resume
automatically.
4 BAND Press to select tuner mode. Press to cycle through 2 AM (MW) bands and 3 FM bands.
5 AUXILIARY Press to select Auxiliary Input mode. Portable audio device (MP3 player, etc.) must be
attached to auxiliary input jack.
6 WEATHER BAND Press to select weather band; use FREQUENCY UP and FREQUENCY DOWN buttons to
adjust to the clearest station.
The weather alert feature, if activated, will automatically switch from the current function to
the weather band if a weather warning is received. See AUDIO / MENU ADJUSTMENT in
this table.
7 TIMER Press to access timer mode. Press to start the timer function; press again to stop timer;
press again to resume timer or press and hold to reset timer and exit from timer mode.
8 DISPLAY SCREEN Displays the time, frequency and activated functions.
9 VOLUME UP Adjusts volume up; current volume (0 - 40) will appear briefly in display screen.
10 AUDIO / MENU
ADJUSTMENT
AUDIO ADJUSTMENT: Press to cycle through bass, treble and balance settings; use
VOLUME UP and VOLUME DOWN to adjust when desired option is displayed; normal
operation will resume automatically.
MENU ADJUSTMENT: Press and hold for three seconds to enter menu adjustment
settings; press to cycle through the following settings; use VOLUME UP and VOLUME
DOWN to adjust when desired option is displayed; normal operation will resume
automatically.
• Beep Confirm (On or Off) - Determines if beep will sound with each button press.
• Operation Region (USA or Europe) - Selects the appropriate region.
• Clock Display (12 or 24) - Selects a 12-hour or 24-hour clock display.
• Display Brightness (Low, Medium or High) - Determines brightness level of display
screen.
• Backlight Colour (Amber or Green) - Determines backlight colour of display screen.
• Power On Volume (0 - 40) - Selects default volume setting when radio is turned on.
• WB Alert (On or Off) - Determines if weather band alert feature is activated.
11 FREQUENCY DOWN Press to manually tune the radio frequency down.
12 FREQUENCY UP Press to manually tune the radio frequency up.
13 VOLUME DOWN Adjusts volume down; current volume (0 - 40) will appear briefly in display screen.
14 SEEK FREQUENCY
DOWN
Press to automatically tune frequency down to next strong station.
15 SEEK FREQUENCY
UP
Press to automatically tune frequency up to next strong station.
16 PRESET STATIONS Used to store and recall stations for each AM and FM band. Press and hold to store
current station; press button to recall station.
17 AUXILIARY INPUT
JACK
Connect line output of portable audio device (MP3 player, etc.) to 3,5 mm (1/8 in) jack and
press AUXILIARY button.
