92 S650 Operation & Maintenance Manual
STARTING THE ENGINE
Standard Key Panel
WARNING
AVOID INJURY OR DEATH
• Engines can have hot parts and hot exhaust gas.
Keep flammable material away.
• Do not use machines in atmosphere containing
explosive gas.
W-2051-1086
Perform the PRE-STARTING PROCEDURE. (See PRE-
STARTING PROCEDURE on Page 88.)
Figure 109
Set the engine speed control to the idle position
[Figure 109].
Figure 110
Turn the key switch to RUN (Item 1) [Figure 110]. The
indicator lights on the left instrument panel will come ON
briefly and the Instrument Panel / monitoring system will
do a self test.
Figure 111
The machine will cycle the air intake heater (glow plugs)
automatically based on temperature. The engine preheat
icon (Item 1) will be ON and the cycle time remaining will
show in the data display (Item 2) [Figure 111].
When the engine preheat icon goes OFF, turn the key
switch to START (Item 2). Release the key when the
engine starts and allow it to return to the RUN position
(Item 1) [Figure 110].
NOTE: Make sure both hand controls (ACS / AHC) or
joysticks (SJC) are in the neutral position
before starting the engine. Do not move the
levers or joysticks from the neutral position
when turning the key to RUN or START with
the BICS™ activated.
WARNING
AVOID INJURY OR DEATH
• Fasten seat belt, start and operate only from the
operator’s seat.
• Never wear loose clothing when working near
machine.
W-2135-1108
P-90525A
P-90687A
2
1
P-76461B
2
1
