ENGINE LUBRICATION SYSTEM (CONT’D)
Removing And Replacing Oil And Filter
For the service interval for replacing the engine oil and
filter.
Run the engine until it is at operating temperature. Stop
the engine.
Open the rear door and remove the drain hose from its
storage position (4) [Figure 10].
Figure 12
Remove the oil drain cap (1) [Figure 12] and drain the oil
into a container. Recycle or dispose of used oil in an
environmentally safe manner.
Install the oil drain cap.
Remove the oil filter (2) [Figure 10] and clean the filter
housing surface.
Use genuine Bobcat filter only.
Put oil on the new filter gasket, install the filter and hand
tighten.
Remove the fill cap (3) [Figure 10].
Put oil in the engine. For the correct quantity (See Fluid
Capacities on Page 24), (See Fluid Capacities on
Page 31). Do not overfill.
Start the engine and let it run for several minutes. Stop
the engine and check for leaks at the filter.
Remove the dipstick (1) [Figure 10] and check the oil
level.
Add oil as needed if it is not at the top mark on the
dipstick. Install the dipstick and close the rear door.
WARNING
AVOID INJURY OR DEATH
Always clean up spilled fuel or oil. Keep heat, flames,
sparks or lighted tobacco away from fuel and oil.
Failure to use care around combustibles can cause
explosion or fire.
W-2103-0508
P-76891
1
