08-08
Intermediate Update 10
REMOVING AND REPLACING COOLANT
Open the rear door and remove the rear grill.
Figure 13
Remove the coolant fill cap (1) [Figure 13].
Remove the plug (2) [Figure 13] located between the oil
filter and the starter. Drain the coolant into a container.
After all the coolant is removed, install the plug. Recycle
or dispose of coolant in an environmentally safe manner.
Mix new coolant in a separate container. (See Fluid
Capacities on Page 24), (See Fluid Capacities on
Page 31).
NOTE: The loader is factory filled with propylene
glycol coolant (purple color). DO NOT mix
propylene glycol with ethylene glycol.
Add premixed coolant, 47% water and 53% propylene
glycol to the recovery tank.
4,3 L of propylene glycol mixed with 3,8 L of water is the
correct mixture of coolant to provide a -37°C (-34°F)
freeze protection.
Fill the tank until it is at the lower marker on the tank and
replace the coolant fill cap.
NOTE: When installing the coolant fill cap, the cap
must be tightened until it clicks.
Run the engine until it is at operating temperature. Stop
the engine. Check the coolant level when cool. Use a
refractometer to check the condition of propylene glycol
in your cooling system. Add coolant as needed.
Install the rear grill and close the rear door.
P-76972
P-76892
1
3
2
