46 T870 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION (CONT’D)
Radio
This machine may be equipped with a radio.
Figure 20
The table on the next page shows the DESCRIPTION and FUNCTION / OPERATION for each of the controls of the radio
[Figure 20].
NOTE: See DISPLAY in the table for clock setting instructions.
NA3090
1
9
11
12
13
14
15
17
8
2
3
4
5
6 7
16
10
