Main Brushes
bObi uses a dual brush cleaning system. It is recommended that you open and
clean bObi’s main brushes after every 2 to 3 cleaning tasks. To open and clean the
brushes:
1
Flip bObi over, so the front wheel
is farthest from you and the side
brush is on your left.
2
Open the locking bar by pressing
the red latch found to the right side
of the main brushes, then lift the
locking tab up from its lower end.
Take out the brushes by lifting the
exposed side up. Then pull to the right.
