03. ASSEMBLY INSTRUCTIONS
FITTING THE CARRIER ON THE BICYCLE
EN
11
J
H5
H2
x2
N
N
L
A
Next step is to fasten the child carrier (A) to the rack attachment system (H). This is an important step to ensure the safety of
the child and the cyclist, so you should make sure to comply strictly with the following instructions. Place the child carrier (A)
as seen in the picture, so that you can insert the safety metallic device (J) of the child carrier (A) and secure it in the insertion
opening for the metallic protection system (H5), marked by the blue arrow. After assuring that it is properly fixed, push down
the child carrier (A), in order to secure it to the rack attachment system (H).
The child carrier will be properly locked to the rack attachment system after you hear a click on both sides, on both
carrier mounting brackets (L), also marked with two blue arrows.
