04 Cylinder instructions
Oxygen cylinder data summary
Cylinder code CD ZD HX ZX
Cylinder order code 101-CD 101-ZD 101-HX 101-ZX
Nominal contents (litres) 460 605 2300 3040
Nominal cylinder pressure (bar) 230 300 230 300
Nominal outlet pressure (bar) 4 4 4 4
Valve outlet fl ow connection 6 mm fi rtree 6 mm fi rtree 6 mm fi rtree 6 mm fi rtree
Valve outlet pressure connection BS 5682 Schrader BS 5682 Schrader BS 5682 Schrader BS 5682 Schrader
Valve operation handwheel handwheel handwheel handwheel
Flow-rate (litres/min) Firtree: 1-15/ Firtree: 1-15/ Firtree: 1-15/ Firtree: 1-15/
Schrader: 40 (nominal) Schrader: 40 (nominal) Schrader: 40 (nominal) Schrader: 40 (nominal)
Dimensions (inc. valve) L x D (mm) 520 x 100 525 x 101 930 x 140 930 x 143
Water capacity (litres) 2.0 2.0 10.0 10.0
Nominal weight full (kg) 3.5 4.1 19.0 14.0
Cylinder duration versus selected fl owrate (based on nominal fl owrate and normal cylinder contents)
Gauge contents
Full (100%) Half (50%) Low (25%)
Size Flowrate (ltr/min) (hr.min) (mins) (hr.min) (mins) (hr.min) (mins)
CD oxygen (460 ltrs) 15 0.30 30 0.15 15 0.07 7
9 0.51 51 0.25 25 0.12 12
6 1.16 76 0.38 38 0.19 19
4 1.55 115 0.57 57 0.28 28
2 3.50 230 1.55 115 0.57 57
ZD oxygen (605 ltrs) 15 0.40 40 0.20 20 0.10 10
9 1.06 66 0.33 33 0.16 16
6 1.40 100 0.50 50 0.25 25
4 2.30 150 1.15 75 0.37 37
2 5.00 300 2.30 150 1.15 75
HX oxygen (2300 ltrs) 15 2.33 153 1.16 76 0.38 38
9 4.15 256 2.07 127 1.03 63
6 6.23 383 3.11 191 1.35 95
4 9.35 575 4.47 287 2.23 143
2 19.10 1150 9.35 575 4.47 287
ZX oxygen (3040 ltrs) 15 3.22 202 1.41 101 0.50 50
9 5.37 337 2.48 168 1.24 84
6 8.26 507 4.13 253 2.06 127
4 12.40 760 6.20 380 3.10 190
2 25.20 1520 12.40 760 6.20 380
HLC/504370/UKS/BAMC/0513
The stripe symbol and the letters BOC are registered trade marks of The BOC Group Limited. Both BOC Limited and The BOC Group Limited are members of The Linde Group,
the parent company of which is Linde AG. Reproduction without permission is strictly prohibited. © Copyright 2013
BOC Healthcare
Customer Service Centre, Priestley Road, Worsley, Manchester M28 2UT
Phone 0800 111 333, Fax 0800 111 555, Email bochealthcare-uk@boc.com, www.bochealthcare.co.uk
Safety information and precautions
• Oxygen is a non-flammable gas, but strongly supports combustion.
• Do not store or use medical gas cylinders near naked flames,
sources of ignition or combustible materials.
• Ensure the oxygen cylinders are stored in a safe and secure area
where they cannot fall over and cause injury.
• Clearly identify the storage areas with appropriate signage.
Ensure separation of full and empty cylinders.
• Store medical gas cylinders separately from industrial and other
non medical cylinders in a well-ventilated area that is clean and dry,
preferably inside.
• Smoking should not be permitted in the vicinity where cylinders
are used or stored.
• Ensure labels remain clearly visible at all times and not removed or
covered. Unauthorised labels/tags must not be fitted.
• Use a suitable trolley to transport large cylinders. Any stationary
cylinder trolley in a ward area should be fixed in place to prevent it
falling over.
• Where available, always use an appropriately designed cylinder
support to hold the cylinder whilst in use adjacent to the patient.
• Ensure the cylinder is set up and tested before placing near the
patient.
• Do not place the cylinder on the patient‘s bed unless there is no
suitable alternative for retaining the cylinder.
• Do not use oil or grease (or any oil-based products which includes
hand creams) in the vicinity of an oxygen cylinder.
• If you need to clean the cylinder do not use any materials which
contain ammonium or chlorine compounds.
• Do not refill or tamper with the cylinder package.
