BOCK FK40 - Assembly of Compressor; Fitting Roller Bearings

40
09665-07.2021-Gb
12 I Assembly of compressor
1
Fitting the roller bearings
Position in
parts list
Parts list position: 2150
Tools: Pressing apparatus
Working course
730
312
2150
- Heat the bearing ange / compressor casing for approx. 20 minutes in a pre-heated (120°C) baking oven
- Insert tolerance ring into the roller bearing, if available
- Press the roller bearings onto the compressor casing and the front bearing ange
CAUTION Risk of burns!
Parts are hot! Use protective gloves!
INFO Use tolerance ring if the bearing seat has a groove!
