42
09665-07.2021-Gb
12 I Assembly of compressor
3
Assembly of the pistons / connecting rods
Position in
parts list
Parts list position: 2040 opt. 2045 or 2030 opt. 2035 together with 2100
Tools: Needle-nosed pliers
Working course
270
280
- Assemble piston and connecting rod with piston pin, use some oil for easier assembly
- Mount circlips with pliers on both sides of the piston pins
