PDR-282X
STEP 1
BE CAREFUL TO ASSEMBLE ALL COMPONENTS
IN THE SEQUENCE THAT THEY ARE PRESENTED.
NOTE:
finger tighten all hardware in this step. DO NOT wrench tighten
until the last step. some components ma
y be pre-assembled.
nylon lock nuts will not fully screw onto bolts, must wrench tighten.
1A. attach cross frame (C) to the bottom front of
right mainframe (A) and left mainframe (B) using:
2 - (#1) M8X15mm hex head bolt
2 - (#2) M8 lock nut
1B. attach cross frame (C) to the bottom back of right
mainframe (A) and left mainframe (B) using:
2 - (#1) M8X15mm hex head bolt
2 - (#2) M8 lock nut
1C. insert end caps into the top opening of right
mainframe (A) and left mainframe (B) using:
2 - (#4) 50X2.5t end cap
10
