PDR-282X
STEP 2
BE CAREFUL TO ASSEMBLE ALL COMPONENTS
IN THE SEQUENCE THAT THEY ARE PRESENTED.
NOTE:
finger tighten all hardware in this step. DO NOT wrench tighten
until the last step. some components ma
y be pre-assembled.
nylon lock nuts will not fully screw onto bolts, must wrench tighten.
2A. attach cross frame (C) to the top front of right
mainframe (A) and left mainframe (B) using:
2 - (#1) M8X15mm hex head bolt
2 - (#2) M8 lock nut
2B. attach cross frame (C) to the top back of right
mainframe (A) and left mainframe (B) using:
2 - (#1) M8X15mm hex head bolt
2 - (#2) M8 lock nut
2C. insert end caps into the bottom openings of right
mainframe (A) and left mainframe (B) using:
4 - (#3) 50X1.8t end cap
