Body Solid SWT1000 - Assembly Instructions

10
STEP
1
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. DO NOT wrench tighten unless instructed.
Some components may be pre-assembled. Nylon lock nuts will not fully screw onto
bolts, they must be wrench tighten to fully go on.
1A. AttachtwoLowerCrossFrames(C)toLowerCenterCross
 Frame(B) using:
2 - (#1) M10x125mm Hex Head Bolt
4 - (#5) M10 Flat Washer
2 - (#8) M10 Nylon Lock Nut
1A. AttachUprights(A)toCrossFrames(C & B)using:
8 - (#3) M10x70mm Button Head Cap Screw
8 - (#5) M10 Flat Washer
8 - (#8) M10 Nylon Lock Nut
8 - (#6) Large Flat Washer ID11xOD28mm
