Body Solid SWT1000 - Page 12

12
STEP
2
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware rst in this step. Wrench tighten ALL hardware at the end of
and after STEP 2B. Some components may be pre-assembled. Nylon lock nuts will not
fully screw onto bolts, they must be wrench tighten to fully go on.
2A.  AttachUpperCenterCrossFrame(D)toUprights(A)using:
2 - (#4) M10x30mm Button Head Cap Screw
2 - (#6) Large Flat Washer ID11xOD28mm
2A. AttachUpperSideCrossFrames(E)toUpperCenterCross
 Frame(D)using:
2 - (#2) M10x75mm Hex Head Bolt
4 - (#5) M10 Flat Washer
2 - (#8) Nylon Lock Nut
2B. AttachUpperSideFrames(E)toUprights(A)using:
2 - (#4) M10x30mm Button Head Cap Screw
2 - (#6) Large Flat Washer ID11xOD28mm
2C. AttachWeightHorns(F)toUprights(A)using:
12 - (#4) M10x30mm Button Head Cap Screw
12 - (#6) Large Flat Washer ID11xOD28mm
12 - (#7) Lock Washer
2D. InsertRubberDonuts(9)ontoWeightHorns(F)
