Gym Placement Planner
Important Notes and Tips:
Ratchet
9/16" Socket
3/4" Socket
9/16" Combination Wrench
3/4" Combination Wrench
Adjustable Wrench
Rubber Mallet
Metric Allen Key Set
2
Recommended Tools
for Assembly
1. Do not tighten bolts until instructed.
2. Two people are required for the safe assembly
of this product.
3. Use window cleaner or water to assist with sliding
roller pads on to tubes.
4. Apply silicone lubricant onto guide rods prior to weight
plate installation.
5. Please allow plastic parts to acclimate to room
temperature before installation or they may be
damaged.
6. Carefully install plastic caps using a rubber mallet.
7. When measuring bolt lengths, only measure the shank.
as shown below.
i.e. 2-1/4" Hex Bolt
0 1/4 1/2 3/4 1/4 1/2 3/4 1/4 1/2 3/4 1/41" 2" 3"
38"
HEIGHT
82"
55"
