BodyCraft HFT - HFT Parts List 2

HFT PARTS LIST 2
4
(21) 10 LB. WEIGHT
PLATE (28 pcs)
(22) RUBBER
DONUT (4pcs)
(23) STACK
SPACER (4pcs)
(24) PLASTIC GUIDE
ROD HOLDER (4pcs)
(27) CABLE (2 pcs)
(29) ANKLE
STRAP
(30) CHIN ASSIST
STRAP
(31) TRICEP
ROPE
(32) SINGLE
HANDLE (2pcs)
(33) CHAIN
(2pcs)
(34) SNAP
HOOK (4pcs)
(36) PULLEY
(16pcs)
(38) END CAP
(4pcs)
(43) PLASTIC
STUDS (9pcs)
48
49
50
51
52
53
54
61
62
63
66
67
68
69
70
2
2
4
10
8
8
4
4
16
28
8
2
8
22
4
TOP PLATE BOLT
1/2" X 4-1/4" HEX BOLT
3/8" X 4-1/4" HEX BOLT
3/8" X 4" BLACK HEX BOLT
3/8" X 2-1/2" HEX BOLT
3/8" X 1-3/4" HEX BOLT
1/4" X 6" HEX BOLT
1/2" WASHER
3/8" CHROMED WASHER
3/8" BLACK WASHER
1/4" WASHER
1/2" NYLON NUT
3/8" CHROMED NYLON NUT
3/8" BLACK NYLON NUT
1/4" NYLON NUT
NO. DESCRIPTION QTY.
48
49
61
62
63
66
67 7068
50
51
52
53
54
69
i.e. 2-1/4"
Hex Bolt
0 1/4 1/2 3/4 1/4 1/2 3/4 1/4 1/2 3/4 1/41" 2" 3"
When measuring bolt lengths, only measure
the shank.
NOTE: If you are missing a listed part, it likely has been pre-installed in
our factory for quality control purposes. Please con�nue with assembly.
*Parts images are not to scale.
