BodyCraft SPT - Step 1: Front and Rear Stabilizer

6
STEP 1 FRONT AND REAR STABILIZER
1. Attach Front Stabilizer (7) to Main Frame (1) on a flat level
surface floor, using two M8 X 4" Domed Bolts (3A), two M8
Washers (6)
3 There are Height Adjusters (72) underneath the Rear End
Caps (54,58) that need to be adjusted until the bike is
totally stable on the floor.
2. Attach Rear Stabilizer (2) to Main Frame (1) on a flat level
surface floor, using two M8 X 4" Domed Bolts (3), two M8
Washers (6)
FRONT REAR
