8
STEP 3 ASSEMBLE HANDLEBAR AND STEM
1. Insert the Handlebar Post (20) into the front tube on Main
Frame (1). You will be able to adjust the height of the
Handlebar Post and then tighten using the preinstalled
Locking Lever (18). If you do not have room to turn the handle
on the Locking Lever, it can disengage from the covered
screw by simply pulling outward on the handle. Then place
the handle where needed to complete tightening, release, and
it will re-engage with the covered screw. Remember to not
make any adjustments past the marked safety line.
2. Remove the preinstalled Sliders Safety screw (14) on the
front of the Handlebar Stem (20) .Then slide Handlebar Slider
(13) into Handlebar stem from back side (20) .Re-insert the
Sliders Safety Screw (19) Insert End cap (74) into the front of
the Handlebar slider (13) and tighten. This Sliders Safety
Screw (14) keeps the Handlebar from sliding all the way off.
