2
1
1
2
(23.6)
0.93 R
3
LOCATIONS
HOLE C WILL BREAK THE OUTER PLANE OF THE GUIDE
ALL DIMENSIONS ARE IN INCHES (mm IN PARENTHESES)
HOLE DIAMETER FOR A, B AND C = 0.191 (4.9)
(13.5)
0.53 R
NDT 4115G
A
C
B
(7.6)
0.30
MARK LETTERS A, B, AND C AS SHOWN
MATERIAL: DELRIN, LUCITE OR EQUIVALENT
TOLERANCES:
_____ NOTES:
X.XXX = ± 0.005
X.XX = ± 0.010
INCHES: MILLIMETERS:
X.XX = ± 0.1
X.X
= ± 0.25
(20.3)
0.80
(21.3)
0.84
(20.8)
0.82
(7.6)
0.30
MARK TRANSDUCER GUIDE NDT4115G AS SHOWN
2130662 S0000459172_V1
Transducer Guide NDT4115G
Figure 3
747
NONDESTRUCTIVE TEST MANUAL
PART 4 54-30-07
Page 8
Nov 15/2015D6-7170
