Boeing 747 - Page 54

2
3
4
3
1
1
2
4
0
1
2
3
4
5 6 7
10 98
NOTCH 1 SIGNAL WITH THE TRANSDUCER AT POSITION Y
NOTCH 2 SIGNAL WITH THE TRANSDUCER AT POSITION Z
POSITIONS FOR OTHER FUSE PINS THAT ARE
LONGITUDINAL
WAVE
SHEAR
WAVE
SOUND PATH OF
INTERNAL REFLECTIONS
DETAIL I
REFERENCE STANDARD BACK SURFACE SIGNAL
WITH THE TRANSDUCER AT POSITION X
INTERNAL REFLECTIONS
THIS FIGURE SHOWS SIGNAL POSITIONS
FOR REFERENCE STANDARD NDT4115.
SEE TABLE 1 FOR THE SPECIFIED SIGNAL
NOT THE SAME AS THIS REFERENCE STANDARD.
NOTE: ____
NOTCH 1
POSITION Y
POSITION X
POSITION Z
NOTCH 2
2130665 S0000459174_V1
Reference Standard Calibration
Figure 5
747
NONDESTRUCTIVE TEST MANUAL
PART 4 54-30-07
Page 10
Nov 15/2015D6-7170
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ALL
