B737
MAINTENANCE MANUAL
EFFECTIVITY
Post ELT STC ST03081AT
23-24-00
PAGE 209
JAN 02/07
(f) 24 Bit Address Protocol (Long Message) Refer to figure 2A and 2B for the Beacon
Test Set display contents of each specific page described below.
1) Page 1 is the main menu screen. Press “1” for view to see received message
or scroll using “up” and “down” arrow keys to view other messages. Use “left”
and “right” arrow keys to scroll between pages.
2) Page 2 contains the Date and Time that the message was received. Also
included is an indication of whether the message was received properly. Verify
that the third or bottom line reads “’S’ TEST OK”.
