7 Version 10.08.2011
Extractor Overview
The AD range provides extraction and filtration of the fume generated by laser
marking, cutting, etching or engraving. These units are of robust design and feature
ease of use with minimal maintenance.
The main components of the AD 350 are shown in fig.5 below. Items may vary
slightly.
Fig 5.
1 Unit/Filter Condition Display
2 On/Off Switch
3 Airflow Control Panel
4 IEC Power Inlet
5 Hose Inlet Connection
6 Cooling Air In
7 Exhausted Air Out
8 Signal / Interface Cable to Laser
