Product description
BOGE Operating instructions for S 40-2...S 341 / SF 40-2...SF 220 series screw compressors
2.1 Technical data
Technical data for S 101 to S 341, part 1
1
) Standard equipment. Mains voltages and frequencies are specified on a plate in the switch cabinet.
2
) Only for 460 V / 60 Hz. The fuse values change in the case of other mains voltages and frequencies.
Air coolingWater cooling
Type S 101 S 125 S 150 S 151 S 180 S 220 S 271 S 341
Dimensions
– Height (silenced) [inch] 69 69 69 79 79 79 84.4 84.4
– Height (super silenced) [inch] 89 89 89 99 99 99 104.1 104.1
– Width (silenced / super silenced) [inch] 93 93 93 89/101 89/101 89/101 122 122
– Depth [inch] 53 53 53 63 63 63 75.2 75.2
Weight
– silenced [lbs.] 4080 4190 4565 5090 5400 5735 9921 11023
– super silenced [lbs.] 4210 4315 4700 5315 5620 5955 10141 11244
Max. sound pressure level [±3 dB(A)]
accord. to DIN 45635, part 13 76/72 79/74 79/74 85/77 85/77 83/74 84/77 87/80
– silenced / super silenced [dB(A)]
Measuring surface dimension
17/18 17/18 17/18 18/19 18/19 18/19 18/19 19/20
– silenced / super silenced [dB(A)]
Sound capacity level
93/90 96/92 96/92 101/93 101/93 101/93 105/99 105/99
– silenced / super silenced [dB(A)]
Max. sound pressure level [±3 dB(A)]
accord. to DIN 45635, part 13 72/70 73/71 73/71 79/71 79/71 79/71 86/79 86/79
– silenced / super silenced [dB(A)]
Measuring surface dimension
17/18 17/18 17/18 18/19 18/19 18/19 18/19 18/19
– silenced / ssuper silenced [dB(A)
Sound pressure capacity
89/88 90/89 90/89 79/90 79/90 97/90 104/98 104/98
– silenced / super silenced [dB(A)]
Compressor
max. final compression temperature [°F] + 230 + 230 + 230 + 230 + 230 + 230 + 230 + 230
Volume flow according to ISO 1217 part C
– p
max
= 100 psig [cfm] 480 580 685 706 861 1024 1208 1498
– p
max
= 115 psig [cfm] 463 555 650 685 823 985 1080 1439
– p
max
= 125 psig [cfm] 463 – – 685 823 950 1080 1439
– p
max
= 150 psig [cfm] 403 484 576 600 735 886 – 1310
– p
max
= 190 psig [cfm] 346 424 501 508 629 766 – 1119
Drive motor
Rated power [Hp] 100 125 150 150 180 200 250 350
Rated speed
– 60 Hz [min
-1
] 3600 3600 3600 3600 3600 1800 1800 1800
Protection type TEFC TEFC TEFC TEFC TEFC TEFC TEFC TEFC
ISO class FFFFFFFF
Electrical connection
Mains voltage
1
) [V]
230/460 460/575 460/575 460/575 460/575 460/575 460/575 460/575
575
Frequency
1
) [Hz] 60 60 60 60 60 60 60 60
Recommended fuse protection
2
) [A]
300/150 175/150 200/175 200/175 300/225 300/250 400 500
125
