BOHLT EKICK 8 PRO - Table of Contents; Technical Information and Parameters

2
Content
1. Technical information and parameters
2. E-scooter diagram
3. Operating the e-scooter
4. How to use the battery and recharge
5. Care and maintenance
6. General trouble shooting
7. Warranty
1. Technical information and parameters
8” foldable battery operated e-scooter
Dimensions open
L x W x H 100 x 12 x 54 cm
Dimensions folded
L x W x H 100 x 30 x 18 cm
Net weight
≥ 13.5 kg
Maximum speed
≤ 23 km/h
Mileage range – Full battery
≥ 25 km
Wheel center distance front/rear
820mm
Maximum loading capacity
< 120kg
DC motor
Motor type
Non gear, no-hall DC brushless
Output rating (W)
250W
Rotation speed (r/min)
700r/min
Rating voltage (V)
36V
Output max. power torque
12.5Nm
Li-ion Battery
Battery type
Li-ion
Battery capacity (Ah)
Optional 8.8Ah/10.4Ah/15.6Ah
Nominal voltage (V)
36V
Duration full recharge (h)
3-5h
E-controller
Low voltage protection (V)
28.5 ± 1V
