Model BMG/BMF Hot Gas Defrost | 60 Hz
Model
Capacity Fan Data
Air Throw*
†
10°F TD
-20°F SST
6°C TD
-29°C SST
No. CFM m
3
h
Diameter
Extended
(Std.)
Diused
(Opt.)
BTUH Watts in. mm ft. m ft. m
6 Fins Per Inch
BMG190 19,000 5,570 2 4,700 7,990 18 457 65 20 50 15
BMG260 26,000 7,620 2 4,500 7,650 18 457 65 20 50 15
BMG310 31,000 9,080 3 7,050 11,990 18 457 65 20 50 15
BMG390 39,000 11,420 3 6,750 11,480 18 457 65 20 50 15
BMG430 43,000 12,590 4 8,800 14,960 18 457 65 20 50 15
BMG520 52,000 15,230 4 8,400 14,280 18 457 65 20 50 15
4 Fins Per Inch
BMF165 16,500 4,830 2 4,900 8,330 18 457 65 20 50 15
BMF220 22,000 6,440 2 4,650 7,910 18 457 65 20 50 15
BMF250 25,000 7,320 3 7,350 12,500 18 457 65 20 50 15
BMF330 33,000 9,670 3 6,975 11,860 18 457 65 20 50 15
BMF370 37,000 10,840 4 9,100 15,470 18 457 65 20 50 15
BMF440 44,000 12,890 4 8,700 14,790 18 457 65 20 50 15
Performance Data
Capacity Correction
Factors For Electric and
Hot Gas Defrost Units
Saturated
Suction
Temperature °F
+20 -10 -20 -30 -40
Saturated
Suction
Temperature °C
-7 -23 -29 -34 -40
Multiply
Capacity By
1.15 1.02 1.00 0.90 0.80
Model BMG/BMF Hot Gas Defrost | 50 Hz
‡
Model
Capacity Fan Data
Air Throw*
†
10°F TD
-20°F SST
6°C TD
-29°C SST
No. CFM m
3
h
Diameter
Extended
(Std.)
Diused
(Opt.)
BTUH Watts in. mm ft. m ft. m
6 Fins Per Inch
BMG190 16,652 4,880 2 4,230 7,190 18 457 60 18.5 45 13.5
BMG260 22,724 6,660 2 4,050 6,890 18 457 60 18.5 45 13.5
BMG310 27,140 7,950 3 6,345 10,790 18 457 60 18.5 45 13.5
BMG390 34,132 10,000 3 6,075 10,330 18 457 60 18.5 45 13.5
BMG430 37,628 11,020 4 7,920 13,460 18 457 60 18.5 45 13.5
BMG520 45,448 13,310 4 7,560 12,850 18 457 60 18.5 45 13.5
4 Fins Per Inch
BMF165 14,444 4,230 2 4,410 7,500 18 457 60 18.5 45 13.5
BMF220 19,228 5,630 2 4,185 7,120 18 457 60 18.5 45 13.5
BMF250 21,896 6,410 3 6,615 11,250 18 457 60 18.5 45 13.5
BMF330 28,888 8,460 3 6,278 10,670 18 457 60 18.5 45 13.5
BMF370 32,384 9,490 4 8,190 13,920 18 457 60 18.5 45 13.5
BMF440 38,456 11,260 4 7,830 13,310 18 457 60 18.5 45 13.5
* Standard molded fan guards allow for extended air throw; optional wire guards promote air diusion
†
Air throw data based on 12-ft. high ceilings with no obstructions where velocity drops to 50 FPM
‡
For EC motors, use 60 Hz capacity and airow values (Units with EC motors operating at 50 Hz will
not see a reduction in performance due to the electronic control of the motor)
