ASSEMBLY - STEP 7
!
Assembly of the electrical components
The hand switch (10) can be mounted on the left
or right side. When aligning the control unit, make
sure that the hand switch connector is aligned
accordingly.
To provide the greatest possible legroom,
the control unit (9) should be mounted on the
side facing away from the handset.
Use the cable holders (H) with screw (G) to x
loose cables. Please remember that this desk is
height adjustable.
The power cable (7) must therefore be able to
follow the movements of the table without obst-
ruction.
7
8
9
8
H
G
F
10
10
I
