Bolens BL160 User Manual

23
Fig. 15
WARNING: Do not remove or alter the line cutting blade assembly. Excessive line
length will make the unit overheat. This may lead to serious personal injury or damage to
the unit.
Fig. 16
Bump Knob
ADJUSTING THE TRIMMING LINE LENGTH
(For units with bump heads)
If the unit is equipped with a bump head, trimming line can be released from the cutting head without
stopping the engine. Before doing so, make sure the cutting head is loaded with line. Refer to the Line
Replacement Addendum.
To release more line, lightly tap the bump knob on the ground (Fig. 16) while operating the unit at high
speed. For best results, tap the bump knob on bare ground or hard soil. Attempting to release line in
tall grass may stall the engine.
NOTE: Do not rest the cutting head on the ground while the unit is running.
Each time the bump knob is tapped, about 1 inch (25.4 mm) of trimming line is released.
NOTE: Always keep the trimming line fully extended. Line release becomes more dicult when the
cutting line gets shorter.
A blade in the cutting head shield will cut the line to the proper length if any excess line is released.

Bolens BL160 Specifications

General

Engine Displacement	25 cc
Engine Type	2-cycle
Cutting Swath	16 inches
Fuel Type	Gasoline
Weight	12.3 lbs
Shaft Type	Straight
Cutting Width	16 inches
Type	String Trimmer
