BOLEX SBM - Preparing the Bolex for a Motor

I
I
I
I
1
2
6
4
4
8
3
2
2
4
1
8
1
6
M P
     
stop
M P
stop
These are all the features that you have to worry about when you mount a motor onto
the Bolex. The spring motor wind handle(#12) has to be removed by rotating it
clockwise.
The spring motor is then disengaged by moving the lever (#8) down to off while
sliding the slide release trigger (#14) towards "M" until the trigger locks into position.
The Exposure control knob (#16) must be turned to "T". Now you are ready to mount
a motor onto the side of the camera
4. Threaded holes for various 
 accessories and motors.
8. Lever for disengaging 
 spring wound motor.
11. Coupling Spindle for  
 electric motor.
14. Slide Release trigger
16. Exposure control knob
12.  Spring motor winding 
 handle
Preparing the Bolex for a motor
