Table 1. Vibrating digger with side discharge
Position
in
Part name
KTM symbol
Number of items
or norm number
Z655
1.
Frame set
5655 - 01 - 001
1
2.
Suspension system studs
5655 - 01 - 002
2
3.
Ploughshare bracket L*
5655 - 02 - 001
1
Ploughshare bracket R*
5655 - 02 - 002
1
4.
Topper ploughshare L*
5655 - 02 - 003
1
Topper ploughshare R*
5655 - 02 - 004
1
5.
Rail L
5655 - 02 - 005
1
Rail R
5655 - 02 - 006
1
6.
Sifting hopper I (front)
5655 - 03 - 005
1
Sifting hopper II (back)
5655 - 03 - 006
1
7.
Rocker lever L*
5655 - 04 - 001
2
8.
Silent block
5655 - 04 - 002
8
9.
Rocker R
5655 - 05 - 001
2
10.
Rocker sleeves
5655 - 05 - 002
8
11.
Support wheel leg set
5655 - 06 - 001
2
12.
Support wheel with sleeves set
5655 - 06 - 002
2
13.
Drive shaft
5655 - 07 - 001
1
14.
Bearing bracket SY507
Y507
2
15.
Sealed bearing SA/FD 207
SA/FD 207
2
16.
Connecting rod
5655 - 08 - 001
2
17.
Bearing 6015 ZZ
6015 ZZ
2
18.
Inner ring W-115
DIN 472
2
19.
Outer ring Z-75
DIN 471
2
20.
Eccentric
5655 - 08 - 002
2
21.
Flywheel
5655 - 09 - 001
1
22.
Drive shaft shield
5655 - 10 - 001
1
23.
Brackets fastening the shield
5655 - 10 - 002
4
24.
Disc coulter
5655 - 11 - 001
2
25.
Coulter bracket
5655 - 11 - 002
2
26.
Coulter hub set
5655 - 11 - 003
2
* L - left / R - right - marking refers to the right and left ploughshare and rocker
