- 29 -
Table 2. Vibrating digger with rear discharge
Poz.
na
Nazwa części
Symbol KTM
Liczba sztuk
rysunku
lub numer normy
Z655/1
1.
Frame set
6551 - 02 - 01
1
2.
Support wheel set L
6551 - 02 - 02
1
3.
Support wheel set R
6551 - 02 - 03
1
4.
Hopper rear bracket set
6551 - 02 - 04
1
5.
Hopper adjustment screw set
6551 - 02 - 05
1
6.
Hopper front bracket set
6551 - 02 - 06
1
7.
Rear bracket arms
6551 - 02 - 07
2
8.
Eccentric set
6551 - 02 - 08
1
9.
Eccentric hub set
6551 - 02 - 09
1
10.
Connecting rod of the eccentric set
6551 - 02 - 10
1
11.
Sifting hopper set
6551 - 02 - 11
1
12.
Ploughshare set
6551 - 02 - 12
1
13.
Front bracket connector
6551 - 02 - 13
4
14.
Distance bushing of the connecting rod
6551 - 02 - 14
2
15.
Screw M14x90 class8.8
PN-M-82101
5
16.
Screw M14x80 class8.8
PN-M-82101
4
17.
Screw M14x70 class8.8
PN-M-82105
2
18.
Screw M14x50 class8.8
PN-M-82105
2
19.
Washer for M14
PN-M-82006
22
20.
Self-locking nut M14
PN-M-82175
9
21.
Screw M12x100 class8.8
PN-M-82101
4
22.
Washer for M12
PN-M-82006
8
23.
Self-locking nut M12
PN-M-82175
4
24.
Self-locking nut M20
PN-M-82175
1
25.
Washer for M20
PN-M-82006
1
26.
Washer 19/42-2
6551 - 02 - 26
20
27.
Washer 25/35-0.5
6551 - 02 - 27
2
28.
Bearing 6207ZZ
SKF
2
28a
Bearing 6205ZZ
SKF
2
29.
Seeger Z-25x2
SKF
1
30.
Seeger Z-35x2.5
SKF
1
31.
Simerblok
6551 - 02 - 31
8
32.
Suspension system studs
6551 - 02 - 32
2
