20
en
CLEANING
SAFETY INSTRUCTIONS
Always unplug the BONECO F100 before you start
cleaning it! Failure to do so can result in electric
shock and fatal injury!
Do not use alcohol or corrosive cleaning agents for
cleaning.
CLEANING THE HOUSING
The BONECO F100 is designed for low-maintenance op-
eration, even when used over many years. In most cases,
a dry cloth can be used for cleaning.
If stubborn dirt is present, clean the housing using a damp
cloth. Add a small amount of dishwashing detergent to
the water.
CLEANING THE FAN BLADES
1. Unscrew the safety screw on the underside of the
housing.
2. Remove the front grill by turning counterclockwise
slightly.
3. Unscrew the safety screw in the middle clockwise.
4. Remove the fan blade and clean it with a damp cloth.
5. Put the unit back together by following the steps in
reverse order.
6. Attach the front grill with the safety screw. When
doing so, pay attention to the position of the screw
on the front grill.

Other manuals for Boneco F100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Boneco F100 and is the answer not in the manual?

Boneco F100 Specifications

General IconGeneral
TypeHousehold blade fan
Airflow610 m³/h
PlacementTable
Noise level55 dB
Blade length150 mm
Control typeButtons
CertificationCE, TÜV, EAC
On/off switchYes
Product colorBlack, White
Auto oscillatingNo
Number of fan blades3
AC input voltage220 - 240 V
Power source typeAC
AC input frequency50 Hz
Power consumption (typical)20 W
Weight and Dimensions IconWeight and Dimensions
Depth202 mm
Width207 mm
Height238 mm
Weight1600 g
