BONFIGLIOLI 700C Series User Manual

-10-
Ingresso
Input
Motore tipo
Motor type
L L1 d
Vite
Screw
N° (Nm)
SAUER DANFOSS
D0
OMR
55,5÷56,3 1" SAE 6B M12x30-8.8 2 86
D2
OMS
67,1÷67,9 SAE 12/24 z14 M12x35-8.8 4 86
D4
OMSS
26,7÷27,3 SAE 12/24 z12 M10x30-8.8 4 50
D5
OMSU (serie2)
60,2÷60,8 SAE 12/24 z12 M10-12.9 4 75
D6
OMR
55,5÷56,3 ø25,4 M12x35-8.8 2 86
D8
OMSU (serie3)
45,7÷46,3 SAE 12/24 z12 M10-8.8 4 50
Y0
SAUER (51C080)
159÷159,8 111,4÷112,2 SAE 12/24 z14 M20x50-8.8 2 415
Y2
SAUER (90K075)-
(90C055)
140,8÷141,6 93,0÷93,8 SAE 12/24 z14 M20x50-8.8 2 415
Y3
SAUER (90K055)
131,6÷132,4 83,8÷84,6 SAE 12/24 z14 M16x40-8.8 2 215
Y4
SAUER (90C075)
141÷141,8 SAE 12/24 z14 M20x55-8.8 2 415
Y5
SAUER M 46 MV
(cartridge)
125,2÷126 SAE 16/32 z15 M16x40-8.8 2 215
EATON / CHAR-LYNN
E2
BEARINGLESS 2000 std
41,6÷42,7 SAE 12/24 z12 M12x35-8.8 4 86
E3
SERIE 2000
56,8÷57,6 SAE 12/24 z14 M12-8.8 4 86
LINDE
G0
HMF50÷HMV55
137,0÷137,8 88,7÷89,5 DIN 5480 30x1,25 z22 M12x40-8.8 4 86
G1
HMF÷HMV 70
132,0÷132,8 84,5÷85,3 DIN 5480 35x2 z16 M12x40-8.8 4 86
G2
HMR÷HMF÷HMV 90
158,5÷159,2 111,0÷111,8 DIN 5480 40x2 z18 M12x45-12.9 6 145
G3
HMV 105
174,2÷175 124,2÷125,0 SAE 16/32 z23 M12x55-8.8 6 86
G4
BMF 35
61,2÷62,0 23,0÷23,8 DIN 5482 25x22 z14 M10x30-8.8 4 50
G7
HMR 135
162,9÷163,7 102,9÷103,7 SAE 16/32 z27 M12x35-8.8 2 86
G7
HMR 135
162,9÷163,7 102,9÷103,7 SAE 16/32 z27 M12x45-8.8 6 86
Y1
LINDE HMV 75
143,8÷144,6 111,4÷112,2 SAE 16/32 z21 M16x45-8.8 2 215
SAE STANDARD
S3
SAE B (n°2 fori / holes)
42,2÷43,0 SAE 16/32 z13 M12-8.8 2 86
S4
SAE BB (n°2 fori / holes)
46,7÷47,5 SAE 16/32 z15 M12-8.8 2 86
S5
SAE C (n°4 fori / holes)
56,8÷57,6 SAE 12/24 z14 M14-8.8 4 140
S6
SAE D (n°4 fori / holes)
75,8÷76,6 SAE 8/16 z13 M20-8.8 4 415
X1
SAE C (n°4 fori / holes)
56,8÷57,6 SAE 16/32 z21 M12-8.8 4 86
X2
SAE C (n°4 fori / holes)
56,8÷57,6 SAE 16/32 z23 M12-8.8 4 86
X3
CHAR-LYNN Serie 2000
56,8÷57,6 SAE 12/24 z14 M12-8.8 2 86
X5
SAE C (n°2 fori / holes)
56,8÷57,6 SAE 16/32 z21 M16-8.8 2 215
X9
SAE D (n°4 fori / holes)
75,0÷76,0 SAE 8/16 z15 M20-8.8 4 415
