BONTEC ST-12 - Step 1: Connecting Support Column to Tempered Glass; Initial Glass Attachment; Pillar Connection and Alignment

2
A (X4)
Rubber Foot
B (X2)
M6x20 Bolt
C (X3)
M6x16 Bolt D6 Metal Washer
D (X7)
D6 Plastic gasket
E (X3)
F (X4)
M6x40 Bolt
G (X4)
M6
H (X2)
Wire Clip Safety Lock
I (X2)
J-1 (X1)
4mm Allen Key
J-2 (X1)
   
  
 
Back side
1
A


Concentric holes
J-1
B
6
2
Back side
!!
Please pay attention to distingui-
shing the frontwards and the
backwards of the support pillar
and the places of the concentric
holes where the arrows point.
2
Wire clip hole
