Insert the part along the direction of the arrow (make sure the
direction of the arrow is perpendicular to the tempered glass )
to find the positions of the corresponding screw holes.
1
6
90°
✓
✕
Back side
correct
incorrect
The support pillar needs to
be maintained at a 45°
angle with the edge of the
glass for the screw holes to
be aligned
!!
