Basic instrucons
Basic Funcons
1. The instant water heater is equipped with leakage protecon. When a leakage occurs, the appliance automacally cuts o the heang output in order to
ensure safety.
2.
Overheating protection: when the outlet water temperature is more than 55
0
Celsius, the appliance will automatically interrupt the heating procedure in
order to prevent burns or injuries.
3. The heang protecon does not funcon during icing condions: when the temperature drops excessively (lower that 0
o
), the appliance will not be heang.
4. Dry burning-resistant protecon.
Using the appliance
1. Aer conrming that the water heater is installed properly, let the water in and close the water inlet valve when water comes out from the water outlet.
2. Close the switch with which you have turned on the water heater. At this me a beeping sound comes from the buzzer.
3. Press POWER to turn on the water heater switch. The display screen lights up. At this me, the outlet water temperature can be set by pressing the UP/
DOWN button. Every time you press the UP button, the temperature rises by one degree (up to 55
o
Celsius). Everytime you press the DOWN
button, the temperature falls by one degree - to a minimum of 30
o
Celsius.
4. Aer seng the outlet temperature, open the inlet valve and the water heater enters into the heang state. The temperature displayed on the display screen
rises gradually unl it reaches the set point and maintains. When the water ow is too large, it must adjusted in order to achieve the set outlet temperature.
When the water flow is on the contrary inadequate (too little), the appliance will stop the heating procedure as the water flow will be required to be
adjusted accordingly. The appliance has the function of overheated protection. When the outlet water temperature exceeds 55
o
Celsius, the instant water
heater will stop the heating procedure. If the water temperature drops to a certain temperature, the appliance will automatically return to the previous
heating procedure.
By closing the water inlet valve, the water heater will stop heating. The appliance has a memory function. When the water inlet valve is
opened again the appliance will automatically enter the working state as before without any re-adjustment. The appliance is quite convenient to use.
Installaon
1.Tools required: percussion drill, hammer, cross screwdriver, wrench, pliers.
2.Materials: wires, matching leakage switch or suitable and safety wiring tools, insulaon packing materials, water pipe ngs, water pipe sealing materials.
3.Please check that the grounding is in compliance with safety regulaons or not, the outside leading wire of the machine is in compliance with electrical safety
regulaons or not.
Installaon steps
1. According to the screw holes size of the machine hanging plate, drill holes in the corresponding posion of the installaon. Fix and install the machine
hanging plate, put the machine on and pull it down slightly, then the machine will rmly hang on its mounng posion.
2.Use suitable water inlet pipe access to cold water port, have it connected or connect to a water switch, and ensure no leaking.
3.Connect corresponding bath apparatus on the heang water outlet of the machine.
4.Connect the earth wire and electric input line of the machine.
Installaon security warning
1. The technicians who will install the appliance must be accordingly qualied.
2. All materials must comply with the relevant technical requirements.
3. Installaons must comply with the local installaon safety requirements and technical specicaons (grounding).
Wall mounted bathroom-kitchen-wash basin
electric, single phase, instant water heater 7 kW
Fig.1 Schemac diagram
of product installaon
and use.
1. ELCB: Right green light is ON = normal / safe operation
2. ELCB: Right green light is flashing = Electric leakage detected
3. HEAT: Left green light is ON = the water is being heated
4. HEAT: Left green light is OFF = No heating is taking place
5.
6.
7.
DOWN: Temperature decreases
POWER: Turn ON or OFF the appliance
UP: Temperature increases
5
6
7
