31. WARNING: Some dust created by power sanding, sawing, grinding, drilling, and other construcon acvies, contains chemicals known [to the State of
California] to cause cancer, birth defects or other reproducve harm. Some examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement or other masonry products
• Arsenic and chromium from chemically treated lumber your risk from these exposures varies, depending on how oen you do this type of work. To reduce
your exposure to these chemicals: work in a well venlated area, and work with approved safety equipment, such as those dust masks that are specially
designed to lter out microscopic parcles. (California Health & Safety Code § 25249.5, et seq.).
32. WARNING: Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause cancer, and birth defects or
other reproducve harm. Wash hands aer handling. (California Health & Safety Code § 25249.5, et seq.)
SAVE THESE INSTRUCTIONS!
Grounding
TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT GROUNDING WIRE CONNECTION: Check with a qualied electrician if you are in doubt as to
whether the outlet is properly grounded. Do not modify the power cord plug provided with the s prayer. Never remove the grounding prong from the p lug.
Do not use the sprayer if the power cord or plug is damaged. If damaged, have it repaired by a service facility before use. If the plug will not t the outlet,
have a proper outlet installed by a qualied electrician.
CAUTION! All electrical equipment connecons including the socket and cables of the machine should only be made by a professional electrician or by a
specialist manufacturer of the Service department of the manufacturer, respecvely!
Extension Cords
1. Grounded sprayers require a three wire extension cord. Double Insulated sprayers can use either a two or three wire extension cord.
2. As the distance from the supply outlet increases, you must use a heavier gauge extension cord. Using extension cords with inadequately sized wire causes
a serious drop in voltage, resulng in loss of power and possible sprayer damage.
3. The smaller the gauge number of the wire, the greater the capacity of the cord. For example, a 14 gauge cord can carry a higher current than a 16 gauge
cord.
4. When using more than one extension cord to make up the total length, make sure each cord contains at least the minimum wire size required.
5. If you are using one extension cord for more than one sprayer, add the nameplate amperes and use the sum to determine the required minimum cord size.
6. If you are using an extension cord outdoors, make sure it is marked with the sux “W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.
7. Make sure the extension cord is properly wired and in good electrical condion. Always replace a damaged extension cord or have it repaired by a qualied
electrician before using it.
8. Protect the extension cords from sharp objects, excessive heat, and damp or wet areas.
Descripon of main parts
Spray gun
Spray p
Motor and
transmission
components
Spray hose
ON / OFF switch
Sucon set lter
Sucon tube
Return pipe
Rack components
Return valve
assembly
WARNING:
This pump should not be used
with textured materials, block
ller, or asphalt sealer.
This pump is available in this ma-
chine. All informaon given for
the stand model applies to the
cart models except where indi-
cated.
Important
Some of the graphics in this man-
ual may not exactly match your
sprayer and spray gun. All infor-
maon and instrucons given in
this manual applies to all models
except where noted.
