E-4
1. Latch 14. Skip Backward Button
2. Turntable Cover 15. Speed Selection Switch (33/45/78 RPM)
3. Latch 16. Tone Arm Clip
4. Carry Handle 17. Power Indicator Light
5. Legs 18. Power & Volume Knob
6. Speakers 19. Earphone / Headphone Jack
7. 45 RPM Adapter 20. Stylus Cartridge
8. Tone Arm 21. Turntable Platter
9. Lift Lever 22. USB Port
10. Mode Button (REC/USB/SD/Bluetooth) 23. SD Card Input
11. Auto Stop & ON/OFF Control 24. Aux-in Port
12. Skip Forward Button 25. RCA Audio Output Jack
13. Play/Pause/Delete Button 26. DC IN Power Adapter Jack
