BORNIAK BBDST-70 - Technical Parameters

Page 5
III. Technical parameters
Model/Typ    


Rated voltage 230V 230V 230V 230V 230V
Power 615W 1115W 1515W 2015W 115W
Power of the
chamber burner
500W 1000W 1400W 1900W 110W
Fuse 8A (1,25A) 10A (1,25A) 8A (1,25A) 10A (1,25A) 1,25 A
Chamber
capacity
70L 70L 150L 150L 2L
Maximum
temperature
120°C 150°C 120°C 150°C -
The Degree of
the housing
tightness
IP20
TECHNICAL PARAMETERS OF THE SMOKER
Width [mm] 630 720 360
Depth [mm] 400 520 180
Height [mm] 1040 1220 250
OVERALL DIMENSIONS (EXTERNAL)
Width [mm] 400 490 -
Depth [mm] 300 420 -
Height [mm] 580 755 -
DIMENSIONS OF THE CHAMBER (INTERNAL)
630 * (720**)
440* (530**)
360* (480**)
400* (520**)
825* (990**)
970* (1135**)
* Typ 70
** Typ 150
