5.8GHz Diversity LCD Screen Receiver Monitor
certain signal strength and stops on that channel , the signal is not found , will be on the
channel before starting the search stopped ; searching process, all the buttons will not
operate ;
5) SOURCE
DIVERSITY： true diversity reception mode , RF A and RF B the signal strength of a display ,
to achieve the best radio reception ; corresponding to the RF A and RF B
indicator LED will flash alternately ;
RF A：RF A single received signal ;
RF B：RF B single received signal ;
AV IN：External input AV signal；
6) POWER:
Press 0.5S boot, then press 0.5S shutdown.
2. JACK：
：：
：
1）RF A AV OUT：RF A receives the output of an AV signal , RF A mode must；
2）RF B AV OUT：RF B receives the output of an AV signal , RF B mode must；
3）DIVERSITY AV OUT：DIVERSITY the received AV signal output , DIVERSITY mode must ；
4）DC/+12V：DC IN, +12 V power supply , the device operating current of 650 mA @ 12V.
