Bosch 1617EVS User Manual

10
Parts List
(39) 1/4-20 x 1″
Carriage Bolt
(40) 1/4-20 x 1
1
⁄2″ Carriage Bolt
(38) Allen-Head Connector Screw
(42) 4mm Hex Key
(37) #10-32 x 5/8″
Countersunk Phillips
Machine Screw
(41) 1/4-20 x 1
3
⁄4″ Carriage Bolt
(46) 1/4-20 x 1
1
⁄2″ Pan-Head
Phillips Machine Screw
(47) #10-24 x 1/2″ Pan-Head
Phillips Machine Screw
(45) #10-32 x 1/2″ Pan-Head
Phillips Machine Screw
(49) 1/4-20
KEPS Nut
(48) #8-32 x 1/2″ Pan-Head
Phillips Machine Screw
(50) 5/16-18 x 1/2″ Pan-Head
Phillips Machine Screw
(51) M4 x 20 Pan-Head Phillips
Machine Screw
(43) #10-32 x 1
″ Pan-Head
Phillips Machine Screw
(44) #10-32 x 3/4″ Countersunk
Phillips Machine Screw

Bosch 1617EVS Specifications

General

Variable Speed	Yes
Speed Range	8, 000 - 25, 000 RPM
Voltage	120V
Type	Router
Amperage	12 Amps
Warranty	1 Year
Motor Power	2.25 HP
Collet Capacity	1/4 In., 1/2 In.
Base Type	Fixed, Plunge
